DIN 6915 Heavy Hex Nut Dimensions
| d | s | e min | h | Pitch |
|---|---|---|---|---|
| M12 | 22 | 23.91 | 10 | 1.75 |
| M16 | 27 | 29.56 | 13 | 2.00 |
| M20 | 32 | 35.03 | 16 | 2.50 |
| M22 | 36 | 39.55 | 18 | 2.50 |
| M24 | 41 | 45.20 | 19 | 3.00 |
| M27 | 46 | 50.35 | 22 | 3.00 |
| M30 | 50 | 55.37 | 24 | 3.50 |
| M36 | 60 | 66.44 | 29 | 4.00 |
DIN 6915 Heavy Hex Nuts Weights
| Size | Weight |
|---|---|
| M12 | 23.3 |
| M16 | 44.8 |
| M20 | 73.9 |
| M22 | 104 |
| M24 | 155 |
| M27 | 224 |
| M30 | 300 |
| M36 | 515 |
Weights are in kilograms per 1,000 pieces unless otherwise specified. All weights are approximations and strictly informative.
